SS02
GY-MESH
7314140000
316/316L stainless steel(Din1.4401/1.4404 or ASTM S31600/31603) is an austenitic stainless steel. Due to the addition of Mo element, it has a great improvement in corrosion resistance and high temperature strength. It can withstand high temperatures up to 1200-1300 degrees and can be used under harsh conditions.After drawn and annealed, 316/316L stainless steel can be produced into wire mesh. Gaoyuan is a manufacturer specializing in the production and sale of 316/316L stainless steel wire mesh
Performance of 316/316L stainless steel wire mesh
Corrosion resistance
Corrosion resistance is better than 304/304L stainless steel wire mesh, with good corrosion resistance in the production of pulp and paper. Moreover, 316/316L stainless steel wire mesh is also resistant to erosion by marine and aggressive industrial atmospheres.
Heat resistance
316/316L stainless steel wire mesh (06Cr17Ni12Mo2) has good oxidation resistance in intermittent use below 871 ° C (1600 ° F) and continuous use above 927 ° C (1700 ° F). In the range of 427 ° C - 857 ° C (800 ° F - 1575 ° F), it is preferable not to continuously use 316 stainless steel, but when 316/316L stainless steel wire mesh is continuously used outside this temperature range, the stainless steel has good heat resistance.
Weave term of 316/316L stainless steel wire mesh
Plain weave ,Twilled weave,Dutch weave, Welded weave, Knitted Weave,Crimped weave
Chemical Composition of 316/316L stainless steel wire mesh
| Certifiction | |||||||||||
| Stainless steel | Chemical Composition | ||||||||||
| AISI | EN/DIN | UNS/ASTM | C | Mn | P | S | Si | Cr | Ni | Mo | Ti |
| 316 | 14401 | S31600 | ≤0.08 | ≤2 | ≤0.045 | ≤0.030 | ≤1 | 16.0-18.0 | 10.0-14.0 | 2.00-3.00 | |
| 316L | 14404 | S31603 | ≤0.03 | ≤2.00 | ≤0.045 | ≤0.030 | ≤1.0 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | |
Mechanical properties of 316/316L stainless steel wire mesh
| Certifiction | ||||||
| Stainless steel | Mechanical properties | |||||
| AISI | EN/DIN | UNS/ASTM | Tensile Strength | Elongation | Melt | Max. Operating Temperature |
| 316 | 14401 | S31600 | 104 Kpsi | 44% | 2500-2550° F | 1600° F |
| 316L | 14404 | S31603 | 104 Kpsi | 44% | 2500-2550° F | 1600° F |
